Technical Data
- Material To Use: LDPE, BLLDPE, BMLLDPE, BHDPE, BPP, BEVA
- Max Production Capacity: 200 ~ 700kg/hr (at ambiend temperature 32�J)
- Max Lay-Flat Width of Film: 500 ~ 3000mm
- Thickness of Film: 0.03 ~ 0.2 mm (Depending on material's property and blown up ratio)
- Screw Dia.: Ø45mm, Ø55mm, Ø65mm, L/D = 30/1�B (Equipped With: AC motor + Inverter) (Screw diameter's selection is subject to film features)
- Whole line from extruder 5 sets upper take-up unit to winder work proportionally with Human-Machine interface controlled by touching screen monitor easy operation.
- 5 layer stacking type of die Adie dia. Ø200 ~ Ø750 mm.
- I.B.C. (Internal bubble cooling) control system and width detect.
- Distribution of inner and outer cooling air.
- 360° horizontal rotary take up unit
- Back to back winding device with tension control.
- C.P.C. (German Brand: EL): Central position control system Enhance film quality and production rate Aminimize film deviation and ensure accuracy of film distribution and winding.
Film Specifications
High transparency puncture resistance high durability Ahigh stand upright excellent seal under lower temperature good lamination anti-crimp good corona treatment increase capacity increase anti-oxidation lower material costs (secondary barrier film)
Application
1. Stand-Up Pouch
2. Soft Tube
3. Soft Drink Pack
4. Lamination Film
5. Protection Film
6. Stretch Film
7. Good Stand Upright & High Transparency Heat Shrinking Film |
